XCMG Manufacturer G04K China Concrete Truck Mixer 4m³ mini mixer price
Summary
- Certification:CE/ISO9001
- Dimension(L*W*H):7270x2280x3345mm
- Weight:6905kg
- Power(W):140 kW
- Model Number:G04K
- Brand Name:XCMG
- Place of Origin:China
Specifications
- Weight:6905.000kg
- Condition:New
- Moving Type:Wheel
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG Manufacturer G04K China Concrete Truck Mixer 4m³ mini mixer.
* On the basis of in-depth and integrative research on the industry, the XCMG new generation truck mixers are system optimized by taking the integrated modularization design to truly realize the integrated innovation.
* Particular mixing technology with continuous trace, original double log spiral technology with changeable lift angle and changeable screw pitch and optimized auxiliary blades and pressure-reducing hole design can make the operation path of the spiral in perfect state and can ensure the best concrete flowing trend in mixing drum and more uniformly discharging.It can effectively solve the blocking problems in concrete pumps caused by nonuniform concrete.
* Optimized chassis matches with upper parts and such parts as front base and accessory beam, rear base and tilted beam, rear base and accessory beam adopt integration design.
* Hydraulic pump, motor and speed reducer of such world-famous brands as ZF, Rexroth, Bonfiglioli, PMP, TOP are adopted to make the power more sufficient, system more steady and reliable and service life longer.
|
Catagory |
Item |
Unit |
Parameter |
|
Overall Parameter |
Model |
|
G04K |
|
Curb weight |
kg |
6905 |
|
|
Max.total weight |
kg |
16000 |
|
|
Outline dimension |
(L×W×H) mm |
7270×2280×3345 |
|
|
Chassis |
Chassis brand |
|
XCMG |
|
Chassis model |
|
NXG3160D3AZAX |
|
|
Steering position |
|
LHD |
|
|
Driving type |
|
4×2 |
|
|
Wheel base |
mm |
3800 |
|
|
Tire |
|
10.00R20 |
|
|
Power take-off |
|
Flywheel |
|
|
Engine |
Model |
|
YC6J190-33 |
|
Max.power |
kW |
140 |
|
|
Displacement |
L |
6.494 |
|
|
Emission standard Euro Ⅲ |
|
Euro Ⅲ |
|
|
Drum system |
Geometric volume |
m³ |
7.7 |
|
Agitating volume |
m³ |
4 |
|
|
Max.diameter of drum |
mm |
1980 |
|
|
Mixing drum length |
mm |
3595 |
|
|
Slanting angle |
° |
15 |
|
|
Rotating speed |
r/min |
0~14 |
|
|
Feeding speed |
m³/min |
≥ 3 |
|
|
Discharge speed |
m³/min |
≥ 2 |
|
|
Discharge residual rate |
% |
< 0.4 |
|
|
Slump scope |
mm |
50~210 |
