XCMG small excavators on wheels XE60WD 6 ton wheel excavator for sale
Summary
- Max Digging Radius:4690mm
- Machine Weight:5900kg
- Maximum Digging Depth:3520mm
- Maximum Digging Height:5830mm
- Bucket Capacity:0.23m3
- Model Number:XE60WD
- Brand Name:XCMG
- Place of Origin:XUZHOU, CHINA
Specifications
- Weight:59000.000kg
- Condition:New
- Moving Type:Other
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG small excavators on wheels XE60WD 6 ton wheel excavator.
XCMG 6 ton wheel excavator XE60WD is one of the most successful and reliable excavator in the world with high efficiency direct injection engine.
The mechanical direct injection technology can make the fuel economy reach the best value, and meet the requirements of environmental protection without post-treatment (DPF).
The integral cylinder has the advantages of increased displacement, low friction loss, stronger structure and lower noise.
After careful design and commissioning, the engine can achieve continuous and stable power output at low speed.
Strong torque can meet the demand of hydraulic system and realize faster working cycle.
|
Model |
|
Unit |
XE60WA |
XE60WD |
|
Operating weight |
|
Kg |
5900 |
5900 |
|
Bucket capacity |
|
m3 |
0.23 |
0.23 |
|
Engine |
Model |
/ |
4TNV98-EXPXG |
4TNV98-EXPXG |
|
|
Output power |
kW/r/min |
41.5/2400 |
41.5/2400 |
|
|
Maximum torque/speed |
N.m |
201/1800 |
201/1800 |
|
|
Displacement |
L |
3.319 |
3.319 |
|
|
Fuel tank |
L |
110 |
110 |
|
Main |
Rated flow |
L/min |
2×60 |
2×60 |
|
performance |
Working Pressure |
MPa |
22 |
22 |
|
|
Hydraulic tank |
L |
120 |
120 |
|
|
Swing speed |
r/min |
8.9 |
9.8 |
|
|
Bucket digging force |
kN |
42.8 |
42.8 |
|
|
Arm digging force |
kN |
25.8 |
25.8 |
|
|
Min. turning radius |
mm |
4690 |
4690 |
|
|
Travel speed |
km/h |
10.5/26.4 |
10.0/30 |
|
|
Gradeability |
% |
0.56 |
0.56 |
|
|
Main pump/Pilot pump |
/ |
2×2 Piston pump |
2×2 Plunger pump |
|
Hydraulic |
|
|
|
|
|
system |
|
|
|
|
|
|
Overall length |
mm |
6230 |
6230 |
|
Appearance |
Overall width |
mm |
1925 |
1925 |
|
size |
Overall height |
mm |
2850 |
2850 |
|
|
Counterweight clearance |
mm |
970 |
970 |
|
|
Min. ground clearance |
mm |
290 |
290 |
|
|
tail turning radius |
mm |
1665 |
1665 |
|
|
Wheel base |
mm |
2100 |
2100 |
|
|
Tread width |
mm |
1600 |
1600 |
|
|
Width of chassis |
mm |
1925 |
1925 |
|
|
Distance from front bridge to rotary center |
mm |
1230 |
1230 |
|
|
Hood height |
mm |
1900 |
1900 |
|
|
Max. digging depth of dozer |
mm |
150 |
150 |
|
|
Dozer(width/height) |
mm |
1925/352 |
1925/352 |
|
Working |
Max. digging radius |
mm |
6120 |
6120 |
|
scope |
Max. digging distance |
mm |
5910 |
5910 |
|
|
Max. digging height |
mm |
5830 |
5830 |
|
|
Max. dumping height |
mm |
4240 |
4240 |
|
|
Max. digging depth |
mm |
3520 |
3520 |
|
|
Maximum depth cut for 2240mm(8 ft) level bottom |
mm |
3140 |
3140 |
|
|
Max. vertical wall digging depth |
mm |
2400 |
2400 |
|
|
Max. lifting height of dozer |
mm |
390 |
390 |
|
Standard |
|
|
|
|
|
Optional 1 |
|
|
0.09/0.18/0.20/0.25/0.3 bucket |
0.09/0.18/0.20/0.25/0.3 bucket |
|
Optional 2 |
|
|
Shade screens, |
Shade screens, |
|
|
|
|
Protective structure |
Protective structure |
