3 Ton Diesel Forklift With Japanese ISUZU Engine

View All >

Model： HH30Z-W1-D

After-sales Service： Engineers available to service machinery overseas

Min Order Quantity： 1 Unit

Delivery Time：

In Stock (Within 7 days)

Production (Within15 to 20 days)

Customization (negociated delivery time)

After-sales Service：

1. It is recommended that you keep in touch with the seller after purchasing offline...

About after-sales service:

1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:

1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.

Inquiry Chat Now

Favorite Products

Product:

3 Ton Diesel Forklift With Japanese ISUZU Engine

Quantity:

- + /Unit

Content:

Or choose from these questions:

What is the best price you can offer?

Do you support customization?

What is the MOQ for this product?

*Email:

Full Name:

Mobile phone:

HH30Z-W1-D

Specs & Compare

Details

Specs & Compare

Select 3 models for comparison

Fork Width

Fork Length

Min Lifting Height

Max Lifting Height

Rated Loading Capacity

Power Source

Type

Model Number

Brand Name

Place of Origin

Storage & Logistics Equipment

HH30Z-W1-D

125mm

1070mm standard/fork extension

3000mm

6000mm

3 T

Diesel Engine

Air/Solid

HH30Z-W1-D

HUAHE

Zhejiang, China

+ Add a Product

Summary

Fork Width: 125mm
Fork Length:1070mm standard/fork extension
Min Lifting Height:3000mm
Max Lifting Height:6000mm
Rated Loading Capacity:3 T
Power Source: Diesel Engine
Type: Air/Solid
Model Number:HH30Z-W1-D
Brand Name:HUAHE
Place of Origin: Zhejiang, China

Specifications

Weight:4300.000kg
Condition:New
Moving Type:Other

Packaging & Shipping

Delivery Lead Time:7 days for ready goods
Minimum Order:1 Piece
Supply Ability:10,000 Set/ Sets per Month
Total Quantity In Stock:Over 5000
Delivery Port:Any Port In China

Generals	Model		Unit	HH30	HH30Z
	Power type			Diesel
	Rated capacity		Kg	3000
	Load center		mm	500
Dimensions	Lift height		mm	3000
	Free lift height		mm	130
	Fork size (L×W×T)		mm	1070×125×45
	Mast inclination F/R		Deg	6°/12°
	Fnt overhang		mm	490
	Overall Dimensions	Length to face of fork	mm	2680
		Overall width	mm	1225
		Mast lowered height	mm	2095
		Overhead guard height	mm	2120
	Turning radius		mm	2460
	Min. right angle aisle width		mm	2105
Performance	Travel speed	Unload I/II	Km/h	9/20
		Full load I/II	Km/h	8.8/18.5
	Lift speed		mm/s	480
	Max. grade ability		%	20
	Max. drawbar pull		Kn	13
	Self weight		Kg	4400
Wheels & Tires	Tires	Front		28×9-15-12PR
		Rear		6.50-10-10PR
	Tread	Front Q	mm	1000
		Rear S	mm	970
	Wheelbase		mm	1700
	Min. ground clearance (unload/full load)	Mast	mm	152/132
		Frame	mm	158/138
Drive units & Control	Battery		V/Ah	12/90
	Engine	Model		C240
		Rated output	Kw/rpm	34.5/2500
		Rated torque	N.m/rpm	139/1800
		Displacement	cc	2369
	Transmission	Type		Hydraulic
		Shift Fwd/Rwd		1/1 Power shift
	Operating pressure		Mpa	17.5
