XCMG 410HP PD410Y China mining crawler bulldozer machine price
Specifications
- Weight:49500.000kg
- Dimension(L*W*H):9716*4314*3928mm
- Engine Brand:Cummins
- Power:410HP
- Dozing Capacity:14.6m3
- Max. lift speed:0.4m/s
- Max. Tilt:1000mm
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG 410HP PD410Y China mining crawler bulldozer machine.
The XCMG PD410Y mining crawler bulldozer which has excellent power, reliability and a long service life. The PD410Y crawler type bulldozer has been developed by the domestic design. Equipped with Cummins KTA19-C525 engine, more powerful and more reliable.
Performance Characteristics:
1.The imported Cummins engine equipped features excellent energy-conservation and environment-friendliness, and strong power.
2.The full-hydraulic maintenance-free wet drive axle features fast response, stable braking, and high safety and reliability.
3.The XCMG new FOPS & ROPS pressurized cab features large space, broad visual field, excellent sealing performance, low noise, and high safety and comfort.
4.Reduces the fuel consumption by 7% and prolongs the lives of parts.
5.It can thoroughly compete and benchmark against foreign imported products to remarkably save the operation and maintenance costs.
6.Improves the working efficiency and reduces the energy loss.
7.The advanced electronic monitoring system incorporates the sound and light warning devices.
|
Description |
Unit |
Specification |
|
|
Engine |
Model |
/ |
KTA19-C525 |
|
Number of cylinder-bore*stroke |
mm |
6-159*159 |
|
|
Displacement |
L |
19 |
|
|
Rated horsepower/revolution |
kW/r/min |
340/2000 |
|
|
Max. torque/revolution |
N.m/r/min |
2030/1400 |
|
|
Min. fuel consumption |
g/kw.h |
217 |
|
|
Track |
Track pitch |
mm |
260.35 |
|
Number of track shoes |
pics |
40 |
|
|
Track gauge |
mm |
2260 |
|
|
Length of track on ground |
mm |
3425 |
|
|
Track width |
mm |
610 |
|
|
Ground pressure |
MPa |
0.101 |
|
|
Ground clearance |
mm |
600 |
|
|
Hydraulic system of work equipment |
Pump type |
/ |
Gear pump |
|
Rated delivery |
L/min |
264 |
|
|
Working pressure |
MPa |
20 |
|
|
Fuel tank |
L |
750 |
|
|
blade |
Blade Max. lift above the ground |
mm |
1620 |
|
Blade Max. drop below the ground |
mm |
749 |
|
|
Max. lift speed |
m/s |
0.4 |
|
|
Max. tilt |
mm |
1000 |
|
|
Pitch adjustment |
0 |
52±2 |
|
|
type |
/ |
Semi U blade |
|
|
Dimension |
mm |
4314*1841 |
|
|
Blade capacity |
m3 |
14.6 |
|
