XCMG Used Concrete Spraying Machine HPC30KI Truck mounted shotcrete machine Price, MACHMALL

Used Equipment > Used Engineering & Construction Machinery > Used Concrete Pump Truck

XCMG Used Concrete Spraying Machine HPC30KI Truck mounted shotcrete machine Price

FOB Price: $35700.000

View All >

Model： HPC30KI

After-sales Service： Engineers available to service machinery overseas

Min Order Quantity： 1 Unit

Delivery Time：

In Stock (Within 7 days)

Production (Within15 to 20 days)

Customization (negociated delivery time)

After-sales Service：

1. It is recommended that you keep in touch with the seller after purchasing offline...

About after-sales service:

1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:

1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.

Inquiry Chat Now

Favorite Products

Product:

XCMG Used Concrete Spraying Machine HPC30KI Truck mounted shotcrete machine Price

Quantity:

- + /Set

Content:

Or choose from these questions:

What is the best price you can offer?

Do you support customization?

What is the MOQ for this product?

*Email:

Full Name:

Mobile phone:

HPC30KI

Specs & Compare

Details

Specs & Compare

Select 3 models for comparison

Certification

Model Number

Brand Name

Place of Origin

Dimension(L*W*H)

Weight

Power(W)

Production Date

Used Equipment

HPC30KI

CE/ISO9001/CCC

HPC30KI

XCMG

Jiangsu, China

9360*2500*3660mm

16000

132 KW

+ Add a Product

Summary

Certification:CE/ISO9001/CCC
Model Number:HPC30KI
Brand Name:XCMG
Place of Origin:Jiangsu, China
Dimension(L*W*H):9360*2500*3660mm
Weight:16000
Power(W):132 KW

Specifications

Weight:16000.000kg
Year:2017

Packaging & Shipping

Delivery Lead Time:7 days for ready goods
Minimum Order:1 Piece
Delivery Port:Any Port In China

XCMG Used Concrete Spraying Machine HPC30KI Truck mounted shotcrete machine Price

1,The lengthening two-stage telescoping boom can realize the max. spraying height of 18m, the farthest front spraying distance of 14.8 and wider spraying range.

2,Swing boom at end is innovatively designed and matched with a spraying mechanism of three DOF and a remote controller with universal joystick to realize more flexible spraying operation without dead angle and meet tunnel construction requirements to the greatest degree.

3,By incorporating Schwing's fully-hydraulic reversing technology, short reversing time, small spraying impulse, low rebound ratio and good spraying planeness are realized.

4,Besides the main power by motor, chassis power can realize boom and outrigger telescoping without access to electricity and condensing agent feeding into IBC-tank; the simultaneous operation of pumping system and high-pressure water pump ensures more convenient and efficient cleaning of overall machine.

5,Quick-open type design can easily realize replacement of delivery pipe, product maintenance and lubricant adding, etc.

6,The operator can directly roll and unroll cable through remote controller and observe the cable's state on real time, safe and convenient.

Description	Unit		Parameter value
Traveling system	Overall weight	kg	16000
	Outline dimension (L×W×H)(Incl. conveying pipe)	mm	9360×2500×3660
	Rated power of engine	kW/rpm	132 /2400
	Emission standard of engine		China Ⅴ
	Gradeability	%	30
	Turning radius	m	9.5
	Max. speed/hour	km/h	90
Spraying system	Max. spraying height	m	18
	Max. spraying width	m	29.6
	Max. front spraying distance	m	15
	Min. permissible tunnel height for spraying operation	m	4
	Max. operation depth	m	7
	Axial rotation of nozzle seat	°	360
	Axial swing of nozzle seat	°	240
	Nozzle brushing along deflection angle X	°	8×360
Pumping system	Max. theoretical spraying capacity	m3/h	30
	Max. pumping pressure	MPa	8
	Concrete cylinder diameter/stroke	mm	180/1000
	Hopper capacity	L	500
	Max. permissible aggregate diameter (pumping/spraying)	mm	22/16
	Burdening type		Rock valve
Air compressor	Volume of air supply	m3/min	10.5
Air compressor	Air pressure	MPa	0.8
Accelerant agent	Delivery pressure	MPa	0.8
Accelerant agent	Accelerant weighing/delivery capacity	l/h	60~600

XCMG STORY

XCMG RECONDITIONED MACHINE

XCMG reconditioned machine is the second-hand machine program launched by XCMG for the post market. XCMG takes advantage of its dealers network to collect the second-hand XCMG machine that falls into strict standards: good condition, full function and low service hours. The returned machine is then disassembled, repaired, painted, rebuilt and tested officially by XCMG, and the product life is therefore extended. The price of XCMG reconditioned machine is far lower than that of the new one, but its performance and safety are not compromised thanks to XCMG's state-of-the-art processes and technologies. In order to dispel customers' concerns, XCMG establishes a strict evaluation system for reconditioned machines and invites SGS to issue third-party certification.

OUR TEAM

150+ SPECIALISTS

150+ specialists participate in the reconditioning process.

Inspection Team

Certified professional accessors who have worked for more than 10 years conduct comprehensive analysis on the machine.

Reconditioning and Repairing Team

Refurbish core parts to restore capacity. Replace all worn parts with genuine XCMG new ones.

Issuing Report Team

Certified examiner inspects, tests and certifies the reconditioned machine. SGS provides the third-party inspection certificate.

OUR FACTORY

REMANUFACTURING FACTORY

RECONDITION PROCESSES

RECONDITION PROCESSES OF THE USED

We maintain a meticulous and rigorous attitude toward quality, focusing on extraordinary creativity, elaborate designs and exquisite craftsmanship.

COLLECTION

Examine the working conditions, conduct static and dynamic assessment on the used machine. Only machines with light deprecation, low working hours and full functions can be collected.

INSPECTION

Certified professional accessors who have worked for more than 10 years conduct comprehensive analysis on the machine. More than 300 details are checked and compared to XCMG standard. Recondition plan is then decided.

RECONDITIONING AND REPAIRING

Refurbish core parts to restore capacity. Replace all worn parts with genuine XCMG new ones.

TESTING

Follow the test procedure, ensure the performance and durability of the machine. Unqualified products are returned to step 3.

READY FOR DELIVERY

Ready for Delivery!!!

ISSUING REPORT

Certified examiner inspects, tests and certifies the reconditioned machine. SGS provides the third-party inspection certificate.

PAINTING

The whole machine is repainted to restore its appearance. Bright as new.

FAQ

FREQUENTLY ASKED QUESTIONS

1.What’s the warranty policy for XCMG reconditioned machines?

The warranty policy does not cover the covering parts and wearing parts. For engine, gearbox, hydraulic pump, distriutor valve and electric system, the warranty period will be 3 months or 500 working hours whichever comes first. If there is any problem within warranty period, XCMG will provide solutions accordingly.

2.How about the quality of your machine?

The procedure of recondition is taking the same criterion of brand new XCMG machines, therefore, quality of machines will be guaranteed. They are ready to work for you and XCMG will provide test report from professtional institute.

3.Are you the original manufacturer?

Yes! XCMG is leading construction machinery industry in China and XCMG can provide a complete range of constrcution machineries.

4.Can you satisfy my special requirement?

As the manufacturer,XCMG will review the special requirement and recondition it as per request (if possible).

5.What is accpetable payment terms?

Usually XCMG will accept T/T before shipment or 100% Letter of Credit at sight.
If any other questions, please feel free to contact with us.
