XCMG Schwing Official 30m concrete pump machine HB30K Chinese small truck mounted concrete pump price, MACHMALL

Engineering & Construction Machinery > Concrete Machinery > Truck Mounted Concrete Pump

XCMG Schwing Official 30m concrete pump machine HB30K Chinese small truck mounted concrete pump price

View All >

After-sales Service： Engineers available to service machinery overseas

Min Order Quantity： 1 Unit

Delivery Time：

In Stock (Within 7 days)

Production (Within15 to 20 days)

Customization (negociated delivery time)

After-sales Service：

1. It is recommended that you keep in touch with the seller after purchasing offline...

About after-sales service:

1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:

1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.

Inquiry Chat Now

Favorite Products

Product:

XCMG Schwing Official 30m concrete pump machine HB30K Chinese small truck mounted concrete pump price

Quantity:

- + /EA

Content:

Or choose from these questions:

What is the best price you can offer?

Do you support customization?

What is the MOQ for this product?

*Email:

Full Name:

Mobile phone:

Specs & Compare

Details

Specs & Compare

Select 3 models for comparison

Dimension(L*W*H)

Weight

Power(W)

Model Number

Brand Name

Place of Origin

Power Type

Certification

Engineering & Construction Machinery

10190×2500×3700MM

20000KG

203000W

HB30K

XCMG

JiangSu,China

CE/ISO9001

+ Add a Product

Summary

Dimension(L*W*H):10190×2500×3700MM
Weight:20000KG
Power(W):203000W
Model Number:HB30K
Brand Name:XCMG
Place of Origin:JiangSu,China
Certification:CE/ISO9001

Specifications

Weight:20000.000kg
Condition:New
Moving Type:Other
Color:Color

Packaging & Shipping

Delivery Lead Time:7 days for ready goods
Minimum Order:1 Piece
Supply Ability:10,000 Set/ Sets per Month
Total Quantity In Stock:Over 5000
Delivery Port:Any Port In China

XCMG Schwing Official 30m concrete pump machine HB30K Chinese small truck mounted concrete pump price

XCMG Schwing Official 30m concrete pump machine HB30K Chinese small truck mounted concrete pump.

XCMG V7 series truck mounted concrete pump is a new generation equipment which is developed by XCMG and SCHWING Germany technology.

It is highly reliable and durable with seven technical highlights. More advanced boom structure technology, More efficient rock valve pumping technology, Steadier stabilizer structure technology, Steadier reversing buffering technology, more reliable fully-hydraulic reversing technology, Ultra-low pressure loss hydraulic system technology, safer and smarter electrical control system.

XCMG Schwing Official 30m concrete pump machine HB30K Chinese small truck mounted concrete pump price

Description	Unit		Parameter value
Outline dimension	mm		10190×2500×3700
Overall weight	kg		20000
Chassis	Model		ZZ5207M521GC1
	Max. speed	km/h	90
	Max. grade-ability	%	35
	Wheelbase	mm	5200
	Tire		11.00R20
Engine	Model		MC07.28-30
	Max. power	kW	203
	Max. torque	N·m/(r/min)	1100/1200-1800
	Displacement	L	6.87
	Emission standard		Eruo III
Pumping system	Theoretical output	m³/h	100
	Concrete pumping pressure	MPa	8
	Theoretical pumping times	Time/min	25
	Delivery cylinder diameter ×stroke	mm	φ230×1600
	Max. diameter of pumping concrete	mm	40
	Filling height	mm	1550
	Concrete slump range	cm	8~23
Placing boom	Reach height	m	29.6
	Reach depth	m	18
	Slewingradius	m	25.7
	Slewing angle	°	±270
	Unfolding angle of the 1st section	°	90
	Unfolding angle of the 2nd section	°	180
	Unfolding angle of the 3rd section	°	250
	Unfolding angle of the 4th section	°	235
	Unfolding angle of the 5th section	°
Stabilizer span	Longitudinal span of stabilizer	mm	6100
	Transverse span of front stabilizer	mm	5555
	Transverse span of rear stabilizer	mm	4810
Others	Lubrication method		Automatic lubrication
	Control method		Manual/remote control
	Volume of water box	L	400

XCMG Schwing Official 30m concrete pump machine HB30K Chinese small truck mounted concrete pump price
